WillAdams
(William Adams (Carbide 3D))
February 21, 2024, 10:29pm
1
as requested on support…
The piece on the left is 90 degrees/square to the grid. The piece on the right has an angle that I don’t know. I want to rotate it however many degrees so those two edges meet perfectly.
which is pretty basic trigonometry.
We have done this sort of thing once before:
EDIT: My first idea didn’t work…this one does:
Here are your two vectors
[image]
TURN OFF SNAP TO GRID
Rotate the vectors (or a copy of them) so that one leg rests along a grid line
[image]
Then Draw a box smaller than the vector bounding area
[image]
Drag the box’s lower left corner so it snaps onto the vertex of the vectors
[image]
Scale the rectangle using the top-middle handle until the top-right handle lines up with the second vector
[image]
Hit Done.
The rectangle is still se…
In this case, it’s pretty simple to draw a rectangle from the point of the rotation to the shorter angle (which length is the hypotenuse of the right angle which we need to measure).
Using the rectangle tool:
start at one end of the angled part:
control-drag-click at the node for the opposite end of the line:
to get the other two sides of a right triangle.
At:
we have some notes on this, including an image showing the formulae — and a couple of links to triangle calculators such as:
We plug in the numbers there. We want to solve for angle beta:
so we plug in the values for side a , 2.5736:
and side b , 1.67:
and we get:
so we rotate by −32.9794:
arriving at:
Done
which lines up as expected:
1 Like
feature request: a “just do it for me” button, lol!!
Just kidding. Thanks for posting this. I’m going to try it and I look forward to putting it to use on other projects too!
-seth
I just tried this technique. Perfect! Thanks again for the education. I’m dumb and never would’ve known to find that angle this way. You guys rock!
1 Like
WillAdams
(William Adams (Carbide 3D))
February 22, 2024, 6:41pm
5
Like @KevBarn14 — you must have been out at a game on the day that was covered in Trigonometry class.
1 Like
HA! Trigonometry class? What the heck is that? I was either playing baseball or making fun of math nerds.
Thanks again, I really appreciate it.
-seth
WillAdams
(William Adams (Carbide 3D))
February 22, 2024, 7:00pm
7
Actually, I’m pretty sure that we went over this in Shop III as well.
See:
and
and to catch up on this sort of thing:
1 Like
