Vcarve Pro with bitsetter

Software Vectric
1

I’m a newbie to all this. I have the trial version of vcarve pro to make sure I can use it before paying $700. I have the bitsetter and followed the video that’s on all the forums to add the post processor. When I went to save the toolpath there was no “Shapeoko (inch) TOOLCHANGE(.gcode)" in the dropdown menu. My only options are "Carbide Motion ATC (inches) (.nc)” and the one for mm. I have the machine set to Shapeoko 3 XXL - Carbide Motion. Not sure what the difference between that and the Default is, but what am I doing wrong?

I tried exiting vcarve pro and going back in and got the same thing.

2

What post processor? Where did you get it? How did you install it?

3

I downloaded the one you posted to github. I followed this video:

4

I recently loaded Vcarve Desktop. Using the Carbide Motion ATC (mm) option that came as an option in the software package worked fine including with the bitsetter. There were a few things that struck me different from Carbide Create that I made a couple tweaks to the post processor, see the commented out lines:
±--------------------------------------------------

  • Commands output at the start of the file
    ±--------------------------------------------------

begin HEADER

“T1”
“G17”
“G21”
“G90”
“M6 T[T]”
+“G0[ZH]”
“G0[XH][YH]”

±--------------------------------------------------

  • Commands output at the end of the file
    ±--------------------------------------------------

begin FOOTER

“M5”
“G0[ZH]”
+“G0[XH][YH]”
“M2”

5

Did you put it in the PostP or the MyPostP folder?

6

I put it in the mypostp folder

7

It should be the ONLY part that shows up then. Can you get a screenshot of your MyPostP folder?

8

image1914×943 82.3 KB

9

Hmmm…maybe a limitation in the trial.

I don’t know what the " Carbide Motion ATC" post is. Sounds like it uses the BitSetter though. Maybe they have one included in V-Carve now.
Can you share that post here or even the resultant gcode?

10

Guessing that. I run it every day in paid version of Aspire. Vectric limits gcode to their “test” files. I have never used carbide create.

11

This is the post processor:

FILE_EXTENSION = “gcode”

UNITS = “INCHES”

LASER_SUPPORT = “YES”

±-----------------------------------------------

  • Line terminating characters
    ±-----------------------------------------------

LINE_ENDING = “[13][10]”

±-----------------------------------------------

  • Block numbering
    ±-----------------------------------------------

LINE_NUMBER_START = 0
LINE_NUMBER_INCREMENT = 10
LINE_NUMBER_MAXIMUM = 999999

+================================================
+

  • Formatting for variables

+================================================

VAR LINE_NUMBER = [N|A|N|1.0]
VAR DWELL_TIME = [DWELL|A|P|1.2]
VAR POWER = [P|C|S|1.0|10.0]
VAR SPINDLE_SPEED = [S|A|S|1.0]
VAR FEED_RATE = [F|C|F|1.1]
VAR X_POSITION = [X|C|X|1.4]
VAR Y_POSITION = [Y|C|Y|1.4]
VAR Z_POSITION = [Z|C|Z|1.4]
VAR X_HOME_POSITION = [XH|A|X|1.4]
VAR Y_HOME_POSITION = [YH|A|Y|1.4]
VAR Z_HOME_POSITION = [ZH|A|Z|1.4]
VAR ARC_CENTRE_I_INC_POSITION = [I|A|I|1.4]
VAR ARC_CENTRE_J_INC_POSITION = [J|A|J|1.4]

+================================================
+

  • Block definitions for toolpath output

+================================================

begin REVISION_COMMENT

“(VECTRIC POST REVISION)”
“([REVISION])”

±--------------------------------------------------

  • Commands output at the start of the file
    ±--------------------------------------------------

begin HEADER

“T1”
“G17”
“G20”
“G90”
“M6 T[T]”
“G0[ZH]”
“G0[XH][YH]”

±--------------------------------------------------

  • Command output after the header to switch spindle on
    ±--------------------------------------------------

begin SPINDLE_ON

“[S]M3”

±--------------------------------------------

  • Commands output for a dwell move
    ±--------------------------------------------

begin DWELL_MOVE

“G4[DWELL]”

±--------------------------------------------------

  • Commands output for tool change
    ±--------------------------------------------------

begin TOOLCHANGE
“M5”
“M6 T[T]”
“[S]M3”

±--------------------------------------------------

  • Commands output for rapid moves
    ±--------------------------------------------------

begin RAPID_MOVE

“G0[Y][Z]”

±--------------------------------------------------

  • Commands output for the plunge move
    ±--------------------------------------------------

begin PLUNGE_MOVE

“G1[Y][Z][F]”

±--------------------------------------------------

  • Commands output for the first feed rate move
    ±--------------------------------------------------

begin FIRST_FEED_MOVE

“G1[Y][Z][F]”

±--------------------------------------------------

  • Commands output for feed rate moves
    ±--------------------------------------------------

begin FEED_MOVE

“G1[Y][Z]”

±--------------------------------------------------

  • Commands output for the first clockwise arc move
    ±--------------------------------------------------

begin FIRST_CW_ARC_MOVE

“G2[Y][I][J][F]”

±--------------------------------------------------

  • Commands output for clockwise arc move
    ±--------------------------------------------------

begin CW_ARC_MOVE

“G2[Y][I][J]”

±--------------------------------------------------

  • Commands output for the first counterclockwise arc move
    ±--------------------------------------------------

begin FIRST_CCW_ARC_MOVE

“G3[Y][I][J][F]”

±--------------------------------------------------

  • Commands output for counterclockwise arc move
    ±--------------------------------------------------

begin CCW_ARC_MOVE

“G3[Y][I][J]”

±--------------------------------------------------

  • Commands output when the jet is turned on
    ±--------------------------------------------------

begin JET_TOOL_ON

“[P]M4”

±--------------------------------------------------

  • Commands output when the jet is turned off
    ±--------------------------------------------------

begin JET_TOOL_OFF

“M5”

±--------------------------------------------------

  • Commands output when the jet power is changed
    ±--------------------------------------------------

begin JET_TOOL_POWER
“[P]M4”

±--------------------------------------------------

  • Commands output at the end of the file
    ±--------------------------------------------------

begin FOOTER

“M5”
“G0[ZH]”
“G0[XH][YH]”
“M2”

12

gcode (part 1)
(VECTRIC POST REVISION)

(4CF7398C82B3419A0D3729E433102951)

T1

G17

G20

G90

M6 T2

G0Z0.8000

G0X0.0000Y0.0000

S18000M3

G0X0.1500Y0.5130Z0.2000

G1Z-0.1155F20.0

G1Y1.2265F60.0

G1Y1.9765

G1Y2.6130

G2X0.4250Y2.8880I0.2750J0.0000

G1X3.3385

G1X4.0885

G1X6.9250

G2X7.2000Y2.6130I0.0000J-0.2750

G1Y1.8995

G1Y1.1495

G1Y0.5130

G2X6.9250Y0.2380I-0.2750J0.0000

G1X4.0115

G1X3.2615

G1X0.4250

G2X0.1500Y0.5130I0.0000J0.2750

G1Z-0.2310F20.0

G1Y1.2265F60.0

G1Z-0.2120

G1Y1.9765

G1Z-0.2310F20.0

G1Y2.6130F60.0

G2X0.4250Y2.8880I0.2750J0.0000

G1X3.3385

G1Z-0.2120

G1X4.0885

G1Z-0.2310F20.0

G1X6.9250F60.0

G2X7.2000Y2.6130I0.0000J-0.2750

G1Y1.8995

G1Z-0.2120

G1Y1.1495

G1Z-0.2310F20.0

G1Y0.5130F60.0

G2X6.9250Y0.2380I-0.2750J0.0000

G1X4.0115

G1Z-0.2120

G1X3.2615

G1Z-0.2310F20.0

G1X0.4250F60.0

G2X0.1500Y0.5130I0.0000J0.2750

G1Z-0.3465F20.0

G1Y1.2265F60.0

G1Z-0.2120

G1Y1.9765

G1Z-0.3465F20.0

G1Y2.6130F60.0

G2X0.4250Y2.8880I0.2750J0.0000

G1X3.3385

G1Z-0.2120

G1X4.0885

G1Z-0.3465F20.0

G1X6.9250F60.0

G2X7.2000Y2.6130I0.0000J-0.2750

G1Y1.8995

G1Z-0.2120

G1Y1.1495

G1Z-0.3465F20.0

G1Y0.5130F60.0

G2X6.9250Y0.2380I-0.2750J0.0000

G1X4.0115

G1Z-0.2120

G1X3.2615

G1Z-0.3465F20.0

G1X0.4250F60.0

G2X0.1500Y0.5130I0.0000J0.2750

G1Z-0.4620F20.0

G1Y1.2265F60.0

G1Z-0.2120

G1Y1.9765

G1Z-0.4620F20.0

G1Y2.6130F60.0

G2X0.4250Y2.8880I0.2750J0.0000

G1X3.3385

G1Z-0.2120

G1X4.0885

G1Z-0.4620F20.0

G1X6.9250F60.0

G2X7.2000Y2.6130I0.0000J-0.2750

G1Y1.8995

G1Z-0.2120

G1Y1.1495

G1Z-0.4620F20.0

G1Y0.5130F60.0

G2X6.9250Y0.2380I-0.2750J0.0000

G1X4.0115

G1Z-0.2120

G1X3.2615

G1Z-0.4620F20.0

G1X0.4250F60.0

G2X0.1500Y0.5130I0.0000J0.2750

G0Z0.2000

M5

M6 T4

S18000M3

G0X1.5840Y0.9369Z0.2000

G1Z0.0000F12.0

G1X1.5683Z-0.0016

G1X1.5525Y0.8935Z-0.0062

G1X1.6007Z-0.0110

G1X1.5840Y0.9369Z-0.0157

G1X1.5683Z-0.0172

G1X1.5525Y0.8935Z-0.0219

G1X1.6007Z-0.0267

G1X1.5840Y0.9369Z-0.0313

G1X1.5683Z-0.0329

G1X1.5525Y0.8935Z-0.0375

G1X1.6007Z-0.0423

G1X1.5840Y0.9369Z-0.0470

G1X1.5683Z-0.0486

G1X1.5634Y0.9235Z-0.0500

G1X1.5683Y0.9369Z-0.0514

G1X1.5840Z-0.0530

G1X1.6007Y0.8935Z-0.0577

G1X1.5525Z-0.0625

G1X1.5683Y0.9369Z-0.0671

G1X1.5840Z-0.0687

G1X1.6007Y0.8935Z-0.0733

G1X1.5525Z-0.0781

G1X1.5683Y0.9369Z-0.0828

G1X1.5840Z-0.0843

G1X1.6007Y0.8935Z-0.0890

G1X1.5525Z-0.0938

G1X1.5683Y0.9369Z-0.0984

G1X1.5840Z-0.1000

G1X1.5683F60.0

G1X1.5525Y0.8935

G1X1.6007

G1X1.5840Y0.9369

G1X1.6695Y1.0615

G1X1.4809

G1X1.3993Y0.8364

G2X1.3625Y0.7689I-0.2405J0.0872

G1X1.7931

G2X1.7580Y0.8317I0.2037J0.1548

G1X1.6695Y1.0615

G0Z0.2000

G0X2.3142Y0.9734

G1Z0.0000F12.0

G1X2.3197Y0.9569Z-0.0017

G1X2.3231Y0.9388Z-0.0036

G1X2.3240Y0.9194Z-0.0055

G1X2.3217Y0.8993Z-0.0076

G1X2.3162Y0.8791Z-0.0097

G1X2.3074Y0.8597Z-0.0118

G1X2.2954Y0.8418Z-0.0139

G1X2.2808Y0.8263Z-0.0161

G1X2.2642Y0.8135Z-0.0182

G1X2.2463Y0.8038Z-0.0202

G1X2.2281Y0.7972Z-0.0222

G1X2.2101Y0.7935Z-0.0240

G1X2.1928Y0.7924Z-0.0257

G1X1.9968Z-0.0454

G1X1.9814Y0.7933Z-0.0469

G1X1.9662Y0.7960Z-0.0485

G1X1.9514Y0.8005Z-0.0500

G1X1.9662Y0.7960Z-0.0515

G1X1.9814Y0.7933Z-0.0531

G1X1.9968Y0.7924Z-0.0546

G1X2.1928Z-0.0743

G1X2.2101Y0.7935Z-0.0760

G1X2.2281Y0.7972Z-0.0778

G1X2.2463Y0.8038Z-0.0798

G1X2.2642Y0.8135Z-0.0818

G1X2.2808Y0.8263Z-0.0839

G1X2.2954Y0.8418Z-0.0861

G1X2.3074Y0.8597Z-0.0882

G1X2.3162Y0.8791Z-0.0903

G1X2.3217Y0.8993Z-0.0924

G1X2.3240Y0.9194Z-0.0945

G1X2.3231Y0.9388Z-0.0964

G1X2.3197Y0.9569Z-0.0983

G1X2.3142Y0.9734Z-0.1000

G2X2.1928Y0.7924I-0.1215J-0.0497F60.0

G1X1.9968

G2X1.8743Y0.8765I0.0000J0.1313

G1X1.7551Y1.1861

G1X1.3936

G1X1.2822Y0.8789

G2X1.1588Y0.7924I-0.1234J0.0447

G1X0.9761

G2X0.8536Y0.9707I0.0000J0.1313

G1X1.3528Y2.2707

G2X1.4754Y2.3549I0.1225J-0.0471

G1X1.6607

G2X1.7822Y2.2734I0.0000J-0.1313

G1X2.3142Y0.9734

G0Z0.2000

G0X2.8913Y0.7689

G1Z0.0000F12.0

G1X3.0656Z-0.0174

G1X3.0425Y0.7885Z-0.0205

G1X3.0229Y0.8072Z-0.0232

G1X3.0045Y0.8267Z-0.0259

G1X2.9870Y0.8471Z-0.0286

G1X2.9705Y0.8686Z-0.0313

G1X2.9513Y0.8975Z-0.0347

G1X2.9269Y0.8331Z-0.0416

G1X2.9114Y0.7997Z-0.0453

G1X2.8913Y0.7689Z-0.0490

G1X2.9014Z-0.0500

G1X2.8913Z-0.0510

G1X2.9114Y0.7997Z-0.0547

G1X2.9269Y0.8331Z-0.0584

G1X2.9513Y0.8975Z-0.0653

G1X2.9705Y0.8686Z-0.0687

G1X2.9870Y0.8471Z-0.0714

G1X3.0045Y0.8267Z-0.0741

G1X3.0229Y0.8072Z-0.0768

G1X3.0425Y0.7885Z-0.0795

G1X3.0656Y0.7689Z-0.0826

G1X2.8913Z-0.1000

G1X3.0656F60.0

G1X3.0425Y0.7885

G1X3.0229Y0.8072

G1X3.0045Y0.8267

G1X2.9870Y0.8471

G1X2.9705Y0.8686

G1X2.9513Y0.8975

G1X2.9269Y0.8331

G2X2.8913Y0.7689I-0.2393J0.0906

G1X0.5750Y0.6442

G1X6.7750

G3X6.7937Y0.6630I0.0000J0.0188

G1Y2.4630

G3X6.7750Y2.4818I-0.0187J0.0000

G1X0.5750

G3X0.5562Y2.4630I0.0000J-0.0187

G1Y0.6630

G3X0.5750Y0.6442I0.0188J0.0000

G0Z0.2000

G0X0.8055Y2.2325

G1Z0.0000F12.0

G1Y1.7326Z-0.0500

G1Y2.2325Z-0.1000

G1Y1.5404F60.0

G1X1.0713Y2.2325

G1X0.8055

G1X0.6809Y2.3572

G1Y0.7689

G1X0.7724

G2X0.7373Y1.0154I0.2037J0.1548

G1X1.2365Y2.3154

G1X1.2571Y2.3572

G1X0.6809

G0Z0.2000

G0X2.0807Y2.2325

G1Z-0.1000F12.0

G1X2.0681F60.0

G1X2.0695Y2.2293

G1X2.0807Y2.2325

G1X2.1804Y2.1212

G1X2.3488

G2X2.5897Y1.9517I0.0000J-0.2559

G1X2.6142Y1.8833

G1X2.6396Y1.9529

G2X2.8800Y2.1212I0.2404J-0.0876

G1X3.0441

G2X3.2079Y2.0619I0.0000J-0.2559

G1X3.2471Y2.0803

G1X3.2826Y2.0941

G1X3.3186Y2.1061

G1X3.3552Y2.1162

G1X3.3922Y2.1245

G1X3.4296Y2.1312

G1X3.4675Y2.1363

G1X3.5056Y2.1398

G1X3.5442Y2.1419

G1X3.5829Y2.1426

G1X3.6207Y2.1420

G1X3.6574Y2.1402

G1X3.6936Y2.1372

G1X3.7293Y2.1328

G1X3.7647Y2.1269

G1X3.7999Y2.1192

G1X3.8348Y2.1096

G1X3.8682Y2.0983

G1X3.8985Y2.0861

G1X3.9357Y2.0685

G1Y2.2236

G2X3.9733Y2.3572I0.2559J0.0000

G1X1.8790

G1X1.8975Y2.3206

G1X2.0068Y2.0534

G2X2.1804Y2.1212I0.1735J-0.1880

G0Z0.2000

G0X2.4485Y2.2325

G1Z0.0000F12.0

G1X2.4940Y2.2171Z-0.0048

G1X2.5375Y2.1958Z-0.0097

G1X2.5780Y2.1691Z-0.0145

G1X2.6144Y2.1378Z-0.0193

G1X2.6509Y2.1691Z-0.0241

G1X2.6913Y2.1958Z-0.0290

G1X2.7349Y2.2171Z-0.0338

G1X2.7803Y2.2325Z-0.0386

G1X2.6664Z-0.0500

G1X2.7803Z-0.0614

G1X2.7349Y2.2171Z-0.0662

G1X2.6913Y2.1958Z-0.0710

G1X2.6509Y2.1691Z-0.0759

G1X2.6144Y2.1378Z-0.0807

G1X2.5780Y2.1691Z-0.0855

G1X2.5375Y2.1958Z-0.0903

G1X2.4940Y2.2171Z-0.0952

G1X2.4485Y2.2325Z-0.1000

G2X2.6144Y2.1378I-0.0997J-0.3672F60.0

G2X2.7803Y2.2325I0.2656J-0.2724

G1X2.4485

G0Z0.2000

G0X3.1437

G1Z0.0000F12.0

G1X3.1822Y2.2199Z-0.0041

G1X3.2192Y2.2031Z-0.0081

G1X3.2402Y2.2114Z-0.0104

G1X3.2824Y2.2253Z-0.0148

G1X3.3084Y2.2325Z-0.0175

G1X3.1437Z-0.0340

G1X3.1822Y2.2199Z-0.0380

G1X3.2192Y2.2031Z-0.0421

G1X3.2402Y2.2114Z-0.0444

G1X3.2824Y2.2253Z-0.0488

G1X3.2940Y2.2286Z-0.0500

G1X3.2824Y2.2253Z-0.0512

G1X3.2402Y2.2114Z-0.0556

G1X3.2192Y2.2031Z-0.0579

G1X3.1822Y2.2199Z-0.0620

G1X3.1437Y2.2325Z-0.0660

G1X3.3084Z-0.0825

G1X3.2824Y2.2253Z-0.0852

G1X3.2402Y2.2114Z-0.0896

G1X3.2192Y2.2031Z-0.0919

G1X3.1822Y2.2199Z-0.0959

G1X3.1437Y2.2325Z-0.1000

G2X3.2192Y2.2031I-0.0997J-0.3672F60.0

G1X3.2402Y2.2114

G1X3.2824Y2.2253

G1X3.3084Y2.2325

G1X3.1437

G0Z0.2000

G0X3.4603Y1.5933

G1Z0.0000F12.0

G1X3.5723Y1.6082Z-0.0113

G1X3.6227Y1.6165Z-0.0164

G1X3.6156Y1.6183Z-0.0171

G1X3.5999Y1.6209Z-0.0187

G1X3.5814Y1.6226Z-0.0206

G1X3.5598Y1.6232Z-0.0228

G1X3.5392Y1.6228Z-0.0248

G1X3.5208Y1.6214Z-0.0267

G1X3.5053Y1.6194Z-0.0282

G1X3.4928Y1.6169Z-0.0295

G1X3.4768Y1.6118Z-0.0312

G1X3.4708Y1.6083Z-0.0319

G1X3.4655Y1.6019Z-0.0327

G1X3.4603Y1.5933Z-0.0337

G1X3.5723Y1.6082Z-0.0450

G1X3.6216Y1.6163Z-0.0500

G1X3.5723Y1.6082Z-0.0550

G1X3.4603Y1.5933Z-0.0663

G1X3.4655Y1.6019Z-0.0673

G1X3.4708Y1.6083Z-0.0681

G1X3.4768Y1.6118Z-0.0688

G1X3.4928Y1.6169Z-0.0705

G1X3.5053Y1.6194Z-0.0718

G1X3.5208Y1.6214Z-0.0733

G1X3.5392Y1.6228Z-0.0752

G1X3.5598Y1.6232Z-0.0772

G1X3.5814Y1.6226Z-0.0794

G1X3.5999Y1.6209Z-0.0813

G1X3.6156Y1.6183Z-0.0829

G1X3.6227Y1.6165Z-0.0836

G1X3.5723Y1.6082Z-0.0887

G1X3.4603Y1.5933Z-0.1000

G1X3.5723Y1.6082F60.0

G1X3.6227Y1.6165

G1X3.6156Y1.6183

G1X3.5999Y1.6209

G1X3.5814Y1.6226

G1X3.5598Y1.6232

G1X3.5392Y1.6228

G1X3.5208Y1.6214

G1X3.5053Y1.6194

G1X3.4928Y1.6169

G1X3.4768Y1.6118

G1X3.4708Y1.6083

G1X3.4655Y1.6019

G1X3.4603Y1.5933

G0Z0.2000

G0X3.0531Y1.5185

G1Z0.0000F12.0

G1X2.8761Y1.0508Z-0.0500

G1X3.0531Y1.5185Z-0.1000

G1X2.8103Y0.8772F60.0

G2X2.6876Y0.7924I-0.1228J0.0465

G1X2.5386

G2X2.4159Y0.8770I0.0000J0.1313

G1X2.0577Y1.8187

G2X2.1804Y1.9966I0.1227J0.0467

G1X2.3488

G2X2.4724Y1.9097I0.0000J-0.1313

G1X2.6133Y1.5166

G1X2.7567Y1.9103

G2X2.8800Y1.9966I0.1233J-0.0449

G1X3.0441

G2X3.1731Y1.8896I0.0000J-0.1313

G1X3.1901Y1.9041

G1X3.2148Y1.9220

G1X3.2407Y1.9381

G1X3.2677Y1.9526

G1X3.2958Y1.9655

G1X3.3249Y1.9769

G1X3.3549Y1.9868

G1X3.3855Y1.9953

G1X3.4168Y2.0024

G1X3.4488Y2.0081

G1X3.4815Y2.0124

G1X3.5147Y2.0155

G1X3.5486Y2.0173

G1X3.5831Y2.0179

G1X3.6168Y2.0174

G1X3.6493Y2.0159

G1X3.6808Y2.0133

G1X3.7114Y2.0095

G1X3.7411Y2.0045

G1X3.7701Y1.9982

G1X3.7982Y1.9905

G1X3.8248Y1.9814

G1X3.8493Y1.9716

G1X3.8722Y1.9611

G1X3.8944Y1.9494

G1X3.9158Y1.9366

G1X3.9363Y1.9224

G1X3.9559Y1.9067

G1X3.9743Y1.8894

G1X3.9910Y1.8710

G1X4.0053Y1.8523

G1X4.0181Y1.8332

G1X4.0295Y1.8134

G1X4.0396Y1.7929

G1X4.0485Y1.7719

G1X4.0561Y1.7503

G1X4.0603Y1.7362

G1Y2.2236

G2X4.1915Y2.3549I0.1312J0.0000

G1X4.3512

G2X4.4824Y2.2236I0.0000J-0.1313

G1Y1.7344

G1X4.4950Y1.7572

G1X4.5125Y1.7846

G1X4.5317Y1.8109

G1X4.5524Y1.8358

G1X4.5748Y1.8593

G1X4.5983Y1.8810

G1X4.6189Y1.8979

G1X4.6395Y1.9134

G1X4.6607Y1.9278

G1X4.6826Y1.9413

G1X4.7051Y1.9537

G1X4.7281Y1.9650

G1X4.7516Y1.9752

G1X4.7756Y1.9843

G1X4.8001Y1.9923

G1X4.8249Y1.9992

G1X4.8502Y2.0050

G1X4.8757Y2.0097

G1X4.9016Y2.0133

G1X4.9277Y2.0159

G1X4.9541Y2.0174

G1X4.9809Y2.0179

G1X5.0103Y2.0173

G1X5.0395Y2.0155

G1X5.0683Y2.0124

G1X5.0967Y2.0079

G1X5.1248Y2.0022

G1X5.1524Y1.9950

G1X5.1795Y1.9866

G1X5.2061Y1.9767

G1X5.2321Y1.9655

G1X5.2574Y1.9529

G1X5.2819Y1.9390

G1X5.3058Y1.9238

G1X5.3288Y1.9074

G1X5.3509Y1.8897

G1X5.3722Y1.8708

G1X5.3927Y1.8506

G1X5.4124Y1.8291

G1X5.4310Y1.8064

G1X5.4483Y1.7828

G1X5.4642Y1.7581

G1X5.4773Y1.7352

G1Y1.8654

G2X5.6086Y1.9966I0.1312J0.0000

G1X5.7523

G2X5.8310Y1.9704I0.0000J-0.1313

G1X5.8456Y1.9773

G1X5.8734Y1.9884

G1X5.9019Y1.9976

G1X5.9310Y2.0051

G1X5.9606Y2.0108

G1X5.9906Y2.0148

G1X6.0211Y2.0172

G1X6.0518Y2.0180

G1X6.0791Y2.0173

G1X6.1059Y2.0155

G1X6.1326Y2.0123

G1X6.1589Y2.0079

G1X6.1849Y2.0021

G1X6.2104Y1.9950

G1X6.2356Y1.9865

G1X6.2602Y1.9768

G1X6.2839Y1.9659

G1X6.3067Y1.9538

G1X6.3287Y1.9404

G1X6.3498Y1.9257

G1X6.3699Y1.9095

G1X6.3887Y1.8918

G1X6.4063Y1.8727

G1X6.4217Y1.8528

G1X6.4349Y1.8332

G1X6.4465Y1.8136

G1X6.4571Y1.7933

G1X6.4665Y1.7725

G1X6.4748Y1.7512

G1X6.4821Y1.7294

G1X6.4883Y1.7072

G1X6.4941Y1.6823

G1X6.4994Y1.6464

G1X6.5027Y1.6047

G1X6.5045Y1.5572

G1X6.5051Y1.5034

G1Y0.9236

G2X6.3739Y0.7924I-0.1312J0.0000

G1X6.2143

G2X6.0830Y0.9236I0.0000J0.1313

G1X6.0827Y1.5167

G1X6.0809Y1.5511

G1X6.0777Y1.5765

G1X6.0742Y1.5917

G1X6.0709Y1.5993

G1X6.0647Y1.6051

G1X6.0540Y1.6110

G1X6.0396Y1.6152

G1X6.0263Y1.6168

G1X6.0041Y1.6164

G1X5.9912Y1.6148

G1X5.9795Y1.6122

G1X5.9687Y1.6088

G1X5.9584Y1.6045

G1X5.9485Y1.5992

G1X5.9387Y1.5926

G1X5.9266Y1.5824

G1X5.9204Y1.5726

G1X5.9151Y1.5601

G1X5.9098Y1.5422

G1X5.9051Y1.5189

G1X5.9016Y1.4903

G1X5.8997Y1.4566

G1X5.8995Y0.9236

G2X5.7682Y0.7924I-0.1312J0.0000

G1X5.6086

G2X5.4773Y0.9236I0.0000J0.1313

G1Y1.0505

G1X5.4643Y1.0275

G1X5.4430Y0.9957

G1X5.4195Y0.9655

G1X5.3938Y0.9373

G1X5.3660Y0.9111

G1X5.3364Y0.8869

G1X5.3049Y0.8649

G1X5.2720Y0.8452

G1X5.2380Y0.8278

G1X5.2034Y0.8127

G1X5.1678Y0.7999

G1X5.1315Y0.7895

G1X5.0946Y0.7814

G1X5.0571Y0.7756

G1X5.0191Y0.7722

G1X4.9814Y0.7711

G1X4.9509Y0.7717

G1X4.9215Y0.7735

G1X4.8924Y0.7766

G1X4.8637Y0.7810

G1X4.8354Y0.7867

G1X4.8076Y0.7938

G1X4.7803Y0.8022

G1X4.7535Y0.8120

G1X4.7274Y0.8232

G1X4.7020Y0.8357

G1X4.6773Y0.8496

G1X4.6533Y0.8649

G1X4.6303Y0.8814

G1X4.6081Y0.8991

G1X4.5868Y0.9181

G1X4.5663Y0.9383

G1X4.5465Y0.9602

G1X4.5279Y0.9833

G1X4.5106Y1.0075

G1X4.4947Y1.0327

G1X4.4824Y1.0549

G1Y0.9236

G2X4.3512Y0.7924I-0.1312J0.0000

G1X4.1915

G2X4.0949Y0.8349I0.0000J0.1313

G2X3.9982Y0.7924I-0.0967J0.0888

G1X3.8315

G2X3.7333Y0.8365I0.0000J0.1313

G1X3.7025Y0.8217

G1X3.6756Y0.8107

G1X3.6488Y0.8013

G1X3.6218Y0.7932

G1X3.5944Y0.7864

G1X3.5667Y0.7808

G1X3.5386Y0.7765

G1X3.5103Y0.7735

G1X3.4817Y0.7717

G1X3.4532Y0.7711

G1X3.4067Y0.7726

G1X3.3841Y0.7744

G1X3.3618Y0.7771

G1X3.3398Y0.7805

G1X3.3181Y0.7849

G1X3.2968Y0.7901

G1X3.2758Y0.7962

G1X3.2553Y0.8033

G1X3.2351Y0.8114

G1X3.2154Y0.8204

G1X3.1962Y0.8305

G1X3.1776Y0.8416

G1X3.1597Y0.8538

G1X3.1424Y0.8669

G1X3.1262Y0.8808

G1X3.1112Y0.8952

G1X3.0972Y0.9100

G1X3.0839Y0.9255

G1X3.0715Y0.9417

G1X3.0600Y0.9586

G1X3.0494Y0.9761

G1X3.0398Y0.9941

G1X3.0312Y1.0126

G1X3.0236Y1.0316

G1X3.0171Y1.0510

G1X3.0117Y1.0706

G1X3.0073Y1.0906

G1X3.0039Y1.1107

G1X3.0015Y1.1310

G1X3.0001Y1.1514

G1X2.9997Y1.1724

G1X3.0004Y1.1967

G1X3.0025Y1.2213

G1X3.0062Y1.2457

G1X3.0114Y1.2699

G1X3.0182Y1.2936

G1X3.0264Y1.3169

G1X3.0362Y1.3396

G1X3.0473Y1.3613

G1X3.0592Y1.3818

G1X3.0721Y1.4012

G1X3.0861Y1.4198

G1X3.1011Y1.4376

G1X3.1172Y1.4545

G1X3.1320Y1.4681

G2X3.0531Y1.5185I0.0265J0.1286

G0Z0.2000

G0X4.5549Y0.7689

G1Z-0.1000F12.0

G1X4.5734F60.0

G1X4.5612Y0.7776

G1X4.5549Y0.7689

G0Z0.2000

G0X5.3850

G1Z-0.1000F12.0

G1X5.4049F60.0

G1X5.3982Y0.7781

G1X5.3850Y0.7689

G0Z0.2000

G0X5.9719

G1Z0.0000F12.0

G1X6.0105Z-0.0039

G1X5.9912Y0.7983Z-0.0074

G1X5.9719Y0.7689Z-0.0109

G1X6.0105Z-0.0148

G1X5.9912Y0.7983Z-0.0183

G1X5.9719Y0.7689Z-0.0218

G1X6.0105Z-0.0257

G1X5.9912Y0.7983Z-0.0292

G1X5.9719Y0.7689Z-0.0327

G1X6.0105Z-0.0366

G1X5.9912Y0.7983Z-0.0401

G1X5.9719Y0.7689Z-0.0436

G1X6.0105Z-0.0475

G1X5.9962Y0.7899Z-0.0500

G1X6.0105Y0.7689Z-0.0525

G1X5.9719Z-0.0564

G1X5.9912Y0.7983Z-0.0599

G1X6.0105Y0.7689Z-0.0634

G1X5.9719Z-0.0673

G1X5.9912Y0.7983Z-0.0708

G1X6.0105Y0.7689Z-0.0743

G1X5.9719Z-0.0782

G1X5.9912Y0.7983Z-0.0817

G1X6.0105Y0.7689Z-0.0852

G1X5.9719Z-0.0891

G1X5.9912Y0.7983Z-0.0926

G1X6.0105Y0.7689Z-0.0961

G1X5.9719Z-0.1000

G1X6.0105F60.0

G1X5.9912Y0.7983

G1X5.9719Y0.7689

G0Z0.2000

G0X6.2856Y2.2325

G1Z0.0000F12.0

G1X6.3213Y2.2206Z-0.0038

G1X6.3582Y2.2060Z-0.0077

G1X6.3942Y2.1894Z-0.0117

G1X6.4298Y2.1706Z-0.0157

G1X6.4650Y2.1492Z-0.0198

G1X6.4997Y2.1250Z-0.0241

G1X6.5335Y2.0977Z-0.0284

G1X6.5445Y2.0873Z-0.0299

G1Y2.2325Z-0.0445

G1X6.4891Z-0.0500

G1X6.5445Z-0.0555

G1Y2.0873Z-0.0701

G1X6.5335Y2.0977Z-0.0716

G1X6.4997Y2.1250Z-0.0759

G1X6.4650Y2.1492Z-0.0802

G1X6.4298Y2.1706Z-0.0843

G1X6.3942Y2.1894Z-0.0883

G1X6.3582Y2.2060Z-0.0923

G1X6.3213Y2.2206Z-0.0962

G1X6.2856Y2.2325Z-0.1000

G1X6.3213Y2.2206F60.0

G1X6.3582Y2.2060

G1X6.3942Y2.1894

G1X6.4298Y2.1706

G1X6.4650Y2.1492

G1X6.4997Y2.1250

G1X6.5335Y2.0977

G1X6.5445Y2.0873

G1Y2.2325

G1X6.2856

G0Z0.2000

G0X5.2278

G1Z0.0000F12.0

G1X5.2601Y2.2225Z-0.0034

G1X5.2989Y2.2081Z-0.0075

G1X5.3370Y2.1916Z-0.0117

G1X5.3803Y2.1697Z-0.0165

G1X5.4203Y2.1960Z-0.0213

G1X5.4636Y2.2171Z-0.0261

G1X5.5089Y2.2325Z-0.0309

G1X5.3181Z-0.0500

G1X5.5089Z-0.0691

G1X5.4636Y2.2171Z-0.0739

G1X5.4203Y2.1960Z-0.0787

G1X5.3803Y2.1697Z-0.0835

G1X5.3370Y2.1916Z-0.0883

G1X5.2989Y2.2081Z-0.0925

G1X5.2601Y2.2225Z-0.0966

G1X5.2278Y2.2325Z-0.1000

G1X5.2601Y2.2225F60.0

G1X5.2989Y2.2081

G1X5.3370Y2.1916

G1X5.3803Y2.1697

G2X5.5089Y2.2325I0.2283J-0.3043

G1X5.2278

G0Z0.2000

G0X4.7315Y2.2319

G1Z-0.1000F12.0

G1X4.7339Y2.2325F60.0

G1X4.7315

G1X4.7315Y2.2319

G1X4.7640Y2.1116

G1X4.7943Y2.1200

G1X4.8249Y2.1270

G1X4.8558Y2.1327

G1X4.8868Y2.1371

G1X4.9180Y2.1402

G1X4.9493Y2.1420

G1X4.9810Y2.1426

G1X5.0155Y2.1419

G1X5.0501Y2.1397

G1X5.0846Y2.1359

G1X5.1189Y2.1306

G1X5.1529Y2.1236

G1X5.1866Y2.1149

G1X5.2198Y2.1045

G1X5.2525Y2.0924

G1X5.2845Y2.0786

G1X5.3158Y2.0630

G1X5.3462Y2.0458

G1X5.3756Y2.0271

G1X5.3982Y2.0109

G2X5.6086Y2.1212I0.2104J-0.1455

G1X5.7523

G2X5.8359Y2.1072I0.0000J-0.2559

G1X5.8671Y2.1173

G1X5.9036Y2.1267

G1X5.9405Y2.1338

G1X5.9776Y2.1388

G1X6.0147Y2.1417

G1X6.0517Y2.1426

G1X6.0848Y2.1418

G1X6.1176Y2.1396

G1X6.1503Y2.1357

G1X6.1828Y2.1302

G1X6.2151Y2.1230

G1X6.2470Y2.1141

G1X6.2785Y2.1036

G1X6.3092Y2.0914

G1X6.3391Y2.0776

G1X6.3683Y2.0622

G1X6.3969Y2.0448

G1X6.4247Y2.0253

G1X6.4517Y2.0036

G1X6.4774Y1.9795

G1X6.5015Y1.9532

G1X6.5227Y1.9259

G1X6.5403Y1.8998

G1X6.5555Y1.8741

G1X6.5692Y1.8478

G1X6.5814Y1.8209

G1X6.5920Y1.7936

G1X6.6012Y1.7659

G1X6.6091Y1.7381

G1X6.6166Y1.7054

G1X6.6232Y1.6604

G1X6.6271Y1.6121

G1X6.6291Y1.5603

G1X6.6297Y1.5041

G1Y0.9236

G2X6.5776Y0.7689I-0.2558J0.0000

G1X6.6691

G1Y2.3572

G1X4.5694

G2X4.6070Y2.2236I-0.2183J-0.1335

G1Y2.0411

G1X4.6199Y2.0490

G1X4.6475Y2.0642

G1X4.6758Y2.0781

G1X4.7047Y2.0906

G1X4.7341Y2.1018

G1X4.7640Y2.1116

G0Z0.2000

G0X4.9591Y1.3945

G1Z0.0000F12.0

G1X4.9599Y1.3656Z-0.0029

G1X4.9621Y1.3415Z-0.0053

G1X4.9669Y1.3145Z-0.0081

G1X4.9718Y1.2985Z-0.0097

G1X4.9752Y1.2917Z-0.0105

G1X4.9771Y1.2897Z-0.0108

G1X4.9831Y1.2896Z-0.0114

G1X4.9859Y1.2931Z-0.0118

G1X4.9917Y1.3087Z-0.0135

G1X4.9970Y1.3334Z-0.0160

G1X4.9998Y1.3563Z-0.0183

G1X5.0013Y1.3841Z-0.0211

G1X5.0014Y1.4138Z-0.0241

G1X4.9999Y1.4384Z-0.0265

G1X4.9958Y1.4667Z-0.0294

G1X4.9909Y1.4847Z-0.0313

G1X4.9859Y1.4954Z-0.0324

G1X4.9830Y1.4986Z-0.0329

G1X4.9767Y1.4984Z-0.0335

G1X4.9740Y1.4952Z-0.0339

G1X4.9686Y1.4808Z-0.0355

G1X4.9635Y1.4577Z-0.0378

G1X4.9608Y1.4360Z-0.0400

G1X4.9593Y1.4095Z-0.0427

G1X4.9591Y1.3945Z-0.0442

G1X4.9599Y1.3656Z-0.0471

G1X4.9621Y1.3415Z-0.0495

G1X4.9630Y1.3363Z-0.0500

G1X4.9621Y1.3415Z-0.0505

G1X4.9599Y1.3656Z-0.0529

G1X4.9591Y1.3945Z-0.0558

G1X4.9593Y1.4095Z-0.0573

G1X4.9608Y1.4360Z-0.0600

G1X4.9635Y1.4577Z-0.0622

G1X4.9686Y1.4808Z-0.0645

G1X4.9740Y1.4952Z-0.0661

G1X4.9767Y1.4984Z-0.0665

G1X4.9830Y1.4986Z-0.0671

G1X4.9859Y1.4954Z-0.0676

G1X4.9909Y1.4847Z-0.0687

G1X4.9958Y1.4667Z-0.0706

G1X4.9999Y1.4384Z-0.0735

G1X5.0014Y1.4138Z-0.0759

G1X5.0013Y1.3841Z-0.0789

G1X4.9998Y1.3563Z-0.0817

G1X4.9970Y1.3334Z-0.0840

G1X4.9917Y1.3087Z-0.0865

G1X4.9859Y1.2931Z-0.0882

G1X4.9831Y1.2896Z-0.0886

G1X4.9771Y1.2897Z-0.0892

G1X4.9752Y1.2917Z-0.0895

G1X4.9718Y1.2985Z-0.0903

G1X4.9669Y1.3145Z-0.0919

G1X4.9621Y1.3415Z-0.0947

G1X4.9599Y1.3656Z-0.0971

G1X4.9591Y1.3945Z-0.1000

G1X4.9599Y1.3656F60.0

G1X4.9621Y1.3415

G1X4.9669Y1.3145

G1X4.9718Y1.2985

G1X4.9752Y1.2917

G1X4.9771Y1.2897

G1X4.9831Y1.2896

G1X4.9859Y1.2931

G1X4.9917Y1.3087

G1X4.9970Y1.3334

G1X4.9998Y1.3563

G1X5.0013Y1.3841

G1X5.0014Y1.4138

G1X4.9999Y1.4384

G1X4.9958Y1.4667

G1X4.9909Y1.4847

G1X4.9859Y1.4954

G1X4.9830Y1.4986

G1X4.9767Y1.4984

G1X4.9740Y1.4952

G1X4.9686Y1.4808

G1X4.9635Y1.4577

G1X4.9608Y1.4360

G1X4.9593Y1.4095

G1X4.9591Y1.3945

G1X4.8345

G1X4.8355Y1.3584

G1X4.8384Y1.3260

G1X4.8430Y1.2976

G1X4.8490Y1.2731

G1X4.8560Y1.2524

G1X4.8638Y1.2354

G1X4.8721Y1.2215

G1X4.8812Y1.2098

G1X4.8979Y1.1933

G1X4.9144Y1.1815

G1X4.9312Y1.1733

G1X4.9499Y1.1678

G1X4.9723Y1.1651

G1X4.9891Y1.1651

G1X5.0110Y1.1678

G1X5.0293Y1.1732

G1X5.0460Y1.1814

G1X5.0625Y1.1933

G1X5.0792Y1.2100

G1X5.0882Y1.2216

G1X5.0965Y1.2357

G1X5.1044Y1.2531

G1X5.1115Y1.2744

G1X5.1176Y1.2997

G1X5.1222Y1.3290

G1X5.1252Y1.3625

G1X5.1262Y1.3998

G1X5.1252Y1.4342

G1X5.1223Y1.4650

G1X5.1178Y1.4921

G1X5.1119Y1.5156

G1X5.1049Y1.5356

G1X5.0971Y1.5522

G1X5.0886Y1.5661

G1X5.0793Y1.5780

G1X5.0623Y1.5948

G1X5.0456Y1.6068

G1X5.0289Y1.6150

G1X5.0106Y1.6204

G1X4.9889Y1.6231

G1X4.9643Y1.6225

G1X4.9432Y1.6188

G1X4.9252Y1.6125

G1X4.9086Y1.6032

G1X4.8920Y1.5899

G1X4.8810Y1.5785

G1X4.8720Y1.5670

G1X4.8638Y1.5533

G1X4.8560Y1.5363

G1X4.8490Y1.5158

G1X4.8430Y1.4913

G1X4.8384Y1.4630

G1X4.8355Y1.4307

G1X4.8345Y1.3945

G0Z0.2000

G0X3.4366Y1.1826

G1Z0.0000F12.0

G1X3.4332Y1.1800Z-0.0004

G1X3.4326Y1.1773Z-0.0007

G1X3.4333Y1.1718Z-0.0013

G1X3.4388Y1.1671Z-0.0020

G1X3.4471Y1.1638Z-0.0029

G1X3.4643Y1.1603Z-0.0046

G1X3.4765Y1.1591Z-0.0059

G1X3.4911Y1.1587Z-0.0073

G1X3.5063Y1.1591Z-0.0088

G1X3.5207Y1.1603Z-0.0103

G1X3.5341Y1.1623Z-0.0116

G1X3.5467Y1.1650Z-0.0129

G1X3.5586Y1.1683Z-0.0142

G1X3.5698Y1.1723Z-0.0154

G1X3.5805Y1.1769Z-0.0165

G1X3.6002Y1.1880Z-0.0188

G1X3.6159Y1.2000Z-0.0208

G1X3.6281Y1.2127Z-0.0225

G1X3.6339Y1.2206Z-0.0235

G1X3.5885Y1.2128Z-0.0281

G1X3.5034Y1.1995Z-0.0367

G1X3.4713Y1.1930Z-0.0400

G1X3.4422Y1.1850Z-0.0430

G1X3.4366Y1.1826Z-0.0436

G1X3.4332Y1.1800Z-0.0440

G1X3.4326Y1.1773Z-0.0443

G1X3.4333Y1.1718Z-0.0449

G1X3.4388Y1.1671Z-0.0456

G1X3.4471Y1.1638Z-0.0465

G1X3.4643Y1.1603Z-0.0482

G1X3.4765Y1.1591Z-0.0495

G1X3.4818Y1.1590Z-0.0500

G1X3.4765Y1.1591Z-0.0505

G1X3.4643Y1.1603Z-0.0518

G1X3.4471Y1.1638Z-0.0535

G1X3.4388Y1.1671Z-0.0544

G1X3.4333Y1.1718Z-0.0551

G1X3.4326Y1.1773Z-0.0557

G1X3.4332Y1.1800Z-0.0560

G1X3.4366Y1.1826Z-0.0564

G1X3.4422Y1.1850Z-0.0570

G1X3.4713Y1.1930Z-0.0600

G1X3.5034Y1.1995Z-0.0633

G1X3.5885Y1.2128Z-0.0719

G1X3.6339Y1.2206Z-0.0765

G1X3.6281Y1.2127Z-0.0775

G1X3.6159Y1.2000Z-0.0792

G1X3.6002Y1.1880Z-0.0812

G1X3.5805Y1.1769Z-0.0835

G1X3.5698Y1.1723Z-0.0846

G1X3.5586Y1.1683Z-0.0858

G1X3.5467Y1.1650Z-0.0871

G1X3.5341Y1.1623Z-0.0884

G1X3.5207Y1.1603Z-0.0897

G1X3.5063Y1.1591Z-0.0912

G1X3.4911Y1.1587Z-0.0927

G1X3.4765Y1.1591Z-0.0941

G1X3.4643Y1.1603Z-0.0954

G1X3.4471Y1.1638Z-0.0971

G1X3.4388Y1.1671Z-0.0980

G1X3.4333Y1.1718Z-0.0987

G1X3.4326Y1.1773Z-0.0993

G1X3.4332Y1.1800Z-0.0996

G1X3.4366Y1.1826Z-0.1000

G1X3.4332Y1.1800F60.0

G1X3.4326Y1.1773

G1X3.4333Y1.1718

G1X3.4388Y1.1671

G1X3.4471Y1.1638

G1X3.4643Y1.1603

G1X3.4765Y1.1591

G1X3.4911Y1.1587

G1X3.5063Y1.1591

G1X3.5207Y1.1603

G1X3.5341Y1.1623

G1X3.5467Y1.1650

G1X3.5586Y1.1683

G1X3.5698Y1.1723

G1X3.5805Y1.1769

G1X3.6002Y1.1880

G1X3.6159Y1.2000

G1X3.6281Y1.2127

G1X3.6339Y1.2206

G1X3.5885Y1.2128

G1X3.5034Y1.1995

G1X3.4713Y1.1930

G1X3.4422Y1.1850

G1X3.4366Y1.1826

G0Z0.2000

G0X1.5713Y1.6709

G1Z0.0000F12.0

G1X1.5405Y1.5887Z-0.0088

G1X1.6022Z-0.0149

G1X1.5713Y1.6709Z-0.0237

G1X1.5405Y1.5887Z-0.0325

G1X1.6022Z-0.0387

G1X1.5713Y1.6709Z-0.0474

G1X1.5623Y1.6469Z-0.0500

G1X1.5713Y1.6709Z-0.0526

G1X1.6022Y1.5887Z-0.0613

G1X1.5405Z-0.0675

G1X1.5713Y1.6709Z-0.0763

G1X1.6022Y1.5887Z-0.0851

G1X1.5405Z-0.0912

G1X1.5713Y1.6709Z-0.1000

G1X1.5405Y1.5887F60.0

G1X1.6022

G1X1.5713Y1.6709

G0Z0.2000

M5

M6 T1

S18000M3

G0X2.2506Y0.9473Z0.2000

G1Z0.0000F10.0

G1X2.2532Y0.9395Z-0.0008

G1X2.2548Y0.9309Z-0.0017

G1X2.2552Y0.9216Z-0.0026

G1X2.2542Y0.9120Z-0.0036

G1X2.2516Y0.9024Z-0.0046

G1X2.2473Y0.8932Z-0.0056

G1X2.2416Y0.8847Z-0.0066

G1X2.2347Y0.8773Z-0.0076

G1X2.2268Y0.8712Z-0.0086

G1X2.2183Y0.8666Z-0.0096

G1X2.2096Y0.8634Z-0.0105

G1X2.2010Y0.8617Z-0.0114

G1X2.1928Y0.8611Z-0.0122

G1X1.9968Z-0.0318

G1X1.9878Y0.8618Z-0.0327

G1X1.9787Y0.8638Z-0.0337

G1X1.9698Y0.8673Z-0.0346

G1X1.9614Y0.8721Z-0.0356

G1X1.9539Y0.8782Z-0.0366

G1X1.9475Y0.8852Z-0.0375

G1X1.9423Y0.8930Z-0.0384

G1X1.9385Y0.9012Z-0.0393

G1X1.9002Y1.0006Z-0.0500

G1X1.9385Y0.9012Z-0.0607

G1X1.9423Y0.8930Z-0.0616

G1X1.9475Y0.8852Z-0.0625

G1X1.9539Y0.8782Z-0.0634

G1X1.9614Y0.8721Z-0.0644

G1X1.9698Y0.8673Z-0.0654

G1X1.9787Y0.8638Z-0.0663

G1X1.9878Y0.8618Z-0.0673

G1X1.9968Y0.8611Z-0.0682

G1X2.1928Z-0.0878

G1X2.2010Y0.8617Z-0.0886

G1X2.2096Y0.8634Z-0.0895

G1X2.2183Y0.8666Z-0.0904

G1X2.2268Y0.8712Z-0.0914

G1X2.2347Y0.8773Z-0.0924

G1X2.2416Y0.8847Z-0.0934

G1X2.2473Y0.8932Z-0.0944

G1X2.2516Y0.9024Z-0.0954

G1X2.2542Y0.9120Z-0.0964

G1X2.2552Y0.9216Z-0.0974

G1X2.2548Y0.9309Z-0.0983

G1X2.2532Y0.9395Z-0.0992

G1X2.2506Y0.9473Z-0.1000

G2X2.1928Y0.8611I-0.0578J-0.0237F60.0

G1X1.9968

G2X1.9385Y0.9012I0.0000J0.0625

G1X1.8023Y1.2549

G1X1.3454

G1X1.2176Y0.9023

G2X1.1588Y0.8611I-0.0588J0.0213

G1X0.9761

G2X0.9178Y0.9460I0.0000J0.0625

G1X1.4170Y2.2460

G2X1.4754Y2.2861I0.0583J-0.0224

G1X1.6607

G2X1.7186Y2.2473I0.0000J-0.0625

G1X2.2506Y0.9473

G0Z0.2000

G0X0.5750Y2.5505

G1Z0.0000F10.0

G1X0.5635Y2.5497Z-0.0012

G1X0.5517Y2.5473Z-0.0024

G1X0.5399Y2.5431Z-0.0036

G1X0.5285Y2.5371Z-0.0049

G1X0.5180Y2.5293Z-0.0062

G1X0.5087Y2.5200Z-0.0075

G1X0.5009Y2.5095Z-0.0088

G1X0.4949Y2.4981Z-0.0101

G1X0.4907Y2.4863Z-0.0114

G1X0.4883Y2.4745Z-0.0126

G1X0.4875Y2.4630Z-0.0137

G1Y2.1003Z-0.0500

G1Y2.4630Z-0.0863

G1X0.4883Y2.4745Z-0.0874

G1X0.4907Y2.4863Z-0.0886

G1X0.4949Y2.4981Z-0.0899

G1X0.5009Y2.5095Z-0.0912

G1X0.5087Y2.5200Z-0.0925

G1X0.5180Y2.5293Z-0.0938

G1X0.5285Y2.5371Z-0.0951

G1X0.5399Y2.5431Z-0.0964

G1X0.5517Y2.5473Z-0.0976

G1X0.5635Y2.5497Z-0.0988

G1X0.5750Y2.5505Z-0.1000

G3X0.4875Y2.4630I0.0000J-0.0875F60.0

G1Y0.6630

G3X0.5750Y0.5755I0.0875J0.0000

G1X6.7750

G3X6.8625Y0.6630I0.0000J0.0875

G1Y2.4630

G3X6.7750Y2.5505I-0.0875J0.0000

G1X0.5750

G0Z0.2000

G0X3.1025Y1.8433

G1Z0.0000F10.0

G1X2.9255Y1.3756Z-0.0500

G1X3.1025Y1.8433Z-0.1000

G1X2.7460Y0.9015F60.0

G2X2.6876Y0.8611I-0.0585J0.0221

G1X2.5386

G2X2.4802Y0.9014I0.0000J0.0625

G1X2.1219Y1.8432

G2X2.1804Y1.9279I0.0584J0.0222

G1X2.3488

G2X2.4077Y1.8865I0.0000J-0.0625

G1X2.6128Y1.3142

G1X2.8213Y1.8868

G2X2.8800Y1.9279I0.0587J-0.0214

G1X3.0441

G2X3.1025Y1.8433I0.0000J-0.0625

G0Z0.2000

G0X3.7536Y1.9314

G1Z0.0000F10.0

G1X3.7780Y1.9247Z-0.0025

G1X3.8009Y1.9169Z-0.0049

G1X3.8221Y1.9084Z-0.0072

G1X3.8419Y1.8993Z-0.0094

G1X3.8607Y1.8895Z-0.0115

G1X3.8785Y1.8788Z-0.0136

G1X3.8952Y1.8673Z-0.0156

G1X3.9108Y1.8547Z-0.0176

G1X3.9252Y1.8412Z-0.0196

G1X3.9381Y1.8269Z-0.0215

G1X3.9494Y1.8122Z-0.0234

G1X3.9596Y1.7969Z-0.0252

G1X3.9688Y1.7809Z-0.0271

G1X3.9770Y1.7643Z-0.0289

G1X3.9843Y1.7470Z-0.0308

G1X3.9907Y1.7290Z-0.0327

G1X3.9962Y1.7106Z-0.0346

G1X4.0012Y1.6901Z-0.0368

G1X4.0054Y1.6606Z-0.0397

G1X4.0081Y1.6246Z-0.0433

G1X4.0097Y1.5816Z-0.0476

G1X4.0099Y1.5580Z-0.0500

G1X4.0097Y1.5816Z-0.0524

G1X4.0081Y1.6246Z-0.0567

G1X4.0054Y1.6606Z-0.0603

G1X4.0012Y1.6901Z-0.0632

G1X3.9962Y1.7106Z-0.0654

G1X3.9907Y1.7290Z-0.0673

G1X3.9843Y1.7470Z-0.0692

G1X3.9770Y1.7643Z-0.0711

G1X3.9688Y1.7809Z-0.0729

G1X3.9596Y1.7969Z-0.0748

G1X3.9494Y1.8122Z-0.0766

G1X3.9381Y1.8269Z-0.0785

G1X3.9252Y1.8412Z-0.0804

G1X3.9108Y1.8547Z-0.0824

G1X3.8952Y1.8673Z-0.0844

G1X3.8785Y1.8788Z-0.0864

G1X3.8607Y1.8895Z-0.0885

G1X3.8419Y1.8993Z-0.0906

G1X3.8221Y1.9084Z-0.0928

G1X3.8009Y1.9169Z-0.0951

G1X3.7780Y1.9247Z-0.0975

G1X3.7536Y1.9314Z-0.1000

G1X3.7780Y1.9247F60.0

G1X3.8009Y1.9169

G1X3.8221Y1.9084

G1X3.8419Y1.8993

G1X3.8607Y1.8895

G1X3.8785Y1.8788

G1X3.8952Y1.8673

G1X3.9108Y1.8547

G1X3.9252Y1.8412

G1X3.9381Y1.8269

G1X3.9494Y1.8122

G1X3.9596Y1.7969

G1X3.9688Y1.7809

G1X3.9770Y1.7643

G1X3.9843Y1.7470

G1X3.9907Y1.7290

G1X3.9962Y1.7106

G1X4.0012Y1.6901

G1X4.0054Y1.6606

G1X4.0081Y1.6246

G1X4.0097Y1.5816

G1X4.0102Y1.5314

G1Y1.3184

G1X4.0108Y1.2181

G1X4.0127Y1.1390

G1X4.0158Y1.0809

G1X4.0196Y1.0470

G1X4.0247Y1.0234

G1X4.0319Y1.0000

G1X4.0413Y0.9769

G1X4.0534Y0.9530

G2X3.9982Y0.8611I-0.0552J-0.0293

G1X3.8315

G2X3.7749Y0.8972I0.0000J0.0625

G1X3.7683Y0.9113

G1X3.7601Y0.9319

G1X3.7456Y0.9225

G1X3.7220Y0.9084

G1X3.6984Y0.8958

G1X3.6747Y0.8846

G1X3.6511Y0.8750

G1X3.6275Y0.8667

G1X3.6036Y0.8595

G1X3.5794Y0.8535

G1X3.5547Y0.8486

13

gcode (part 2):

G1X3.5297Y0.8447

G1X3.5044Y0.8420

G1X3.4788Y0.8404

G1X3.4530Y0.8398

G1X3.4111Y0.8412

G1X3.3712Y0.8452

G1X3.3330Y0.8520

G1X3.3146Y0.8565

G1X3.2967Y0.8617

G1X3.2792Y0.8677

G1X3.2622Y0.8745

G1X3.2458Y0.8821

G1X3.2299Y0.8905

G1X3.2145Y0.8997

G1X3.1998Y0.9096

G1X3.1857Y0.9204

G1X3.1724Y0.9318

G1X3.1599Y0.9437

G1X3.1483Y0.9560

G1X3.1374Y0.9688

G1X3.1272Y0.9821

G1X3.1178Y0.9958

G1X3.1092Y1.0101

G1X3.1014Y1.0247

G1X3.0944Y1.0398

G1X3.0882Y1.0553

G1X3.0829Y1.0711

G1X3.0784Y1.0872

G1X3.0748Y1.1037

G1X3.0720Y1.1204

G1X3.0700Y1.1373

G1X3.0688Y1.1545

G1X3.0684Y1.1721

G1X3.0690Y1.1927

G1X3.0708Y1.2132

G1X3.0739Y1.2334

G1X3.0782Y1.2532

G1X3.0837Y1.2727

G1X3.0905Y1.2918

G1X3.0985Y1.3104

G1X3.1076Y1.3283

G1X3.1176Y1.3454

G1X3.1283Y1.3615

G1X3.1399Y1.3770

G1X3.1523Y1.3916

G1X3.1655Y1.4055

G1X3.1795Y1.4185

G1X3.1943Y1.4306

G1X3.2096Y1.4417

G1X3.2407Y1.4609

G1X3.2732Y1.4773

G1X3.3074Y1.4913

G1X3.3437Y1.5028

G1X3.3735Y1.5097

G1X3.4082Y1.5162

G1X3.4484Y1.5224

G1X3.5826Y1.5402

G1X3.6576Y1.5530

G1X3.6899Y1.5597

G1X3.7245Y1.5680

G1X3.7241Y1.5825

G1X3.7224Y1.5996

G1X3.7198Y1.6143

G1X3.7165Y1.6265

G1X3.7127Y1.6362

G1X3.7087Y1.6436

G1X3.7046Y1.6492

G1X3.6956Y1.6577

G1X3.6789Y1.6685

G1X3.6641Y1.6754

G1X3.6480Y1.6811

G1X3.6295Y1.6857

G1X3.6087Y1.6891

G1X3.5856Y1.6913

G1X3.5600Y1.6920

G1X3.5359Y1.6915

G1X3.5139Y1.6899

G1X3.4942Y1.6873

G1X3.4768Y1.6838

G1X3.4619Y1.6797

G1X3.4494Y1.6750

G1X3.4391Y1.6699

G1X3.4310Y1.6646

G1X3.4237Y1.6586

G1X3.4164Y1.6508

G1X3.4090Y1.6412

G1X3.4016Y1.6295

G1X3.3944Y1.6155

G1X3.3875Y1.5992

G1X3.3810Y1.5807

G1X3.3746Y1.5583

G2X3.3061Y1.5135I-0.0601J0.0171

G1X3.1500Y1.5348

G2X3.0976Y1.6110I0.0084J0.0619

G1X3.1037Y1.6369

G1X3.1111Y1.6630

G1X3.1196Y1.6881

G1X3.1292Y1.7121

G1X3.1400Y1.7351

G1X3.1520Y1.7570

G1X3.1651Y1.7778

G1X3.1796Y1.7975

G1X3.1956Y1.8162

G1X3.2134Y1.8337

G1X3.2326Y1.8500

G1X3.2532Y1.8649

G1X3.2751Y1.8786

G1X3.2983Y1.8910

G1X3.3227Y1.9022

G1X3.3483Y1.9122

G1X3.3748Y1.9210

G1X3.4022Y1.9286

G1X3.4304Y1.9350

G1X3.4594Y1.9401

G1X3.4892Y1.9441

G1X3.5197Y1.9469

G1X3.5511Y1.9486

G1X3.5831Y1.9492

G1X3.6146Y1.9487

G1X3.6448Y1.9473

G1X3.6737Y1.9449

G1X3.7015Y1.9414

G1X3.7281Y1.9370

G1X3.7536Y1.9314

G0Z0.2000

G0X4.3512Y0.8611

G1Z0.0000F10.0

G1X4.1915Z-0.0160

G1X4.1825Y0.8618Z-0.0169

G1X4.1732Y0.8639Z-0.0178

G1X4.1640Y0.8676Z-0.0188

G1X4.1552Y0.8728Z-0.0198

G1X4.1473Y0.8794Z-0.0209

G1X4.1407Y0.8873Z-0.0219

G1X4.1355Y0.8961Z-0.0229

G1X4.1318Y0.9053Z-0.0239

G1X4.1297Y0.9146Z-0.0249

G1X4.1290Y0.9236Z-0.0258

G1Y1.1659Z-0.0500

G1Y0.9236Z-0.0742

G1X4.1297Y0.9146Z-0.0751

G1X4.1318Y0.9053Z-0.0761

G1X4.1355Y0.8961Z-0.0771

G1X4.1407Y0.8873Z-0.0781

G1X4.1473Y0.8794Z-0.0791

G1X4.1552Y0.8728Z-0.0802

G1X4.1640Y0.8676Z-0.0812

G1X4.1732Y0.8639Z-0.0822

G1X4.1825Y0.8618Z-0.0831

G1X4.1915Y0.8611Z-0.0840

G1X4.3512Z-0.1000

G1X4.1915F60.0

G2X4.1290Y0.9236I0.0000J0.0625

G1Y2.2236

G2X4.1915Y2.2861I0.0625J0.0000

G1X4.3512

G2X4.4137Y2.2236I0.0000J-0.0625

G1Y0.9236

G2X4.3512Y0.8611I-0.0625J0.0000

G0Z0.2000

G0X4.8867Y1.9418

G1Z0.0000F10.0

G1X4.9097Y1.9451Z-0.0023

G1X4.9331Y1.9474Z-0.0047

G1X4.9567Y1.9487Z-0.0070

G1X4.9808Y1.9492Z-0.0094

G1X5.0074Y1.9486Z-0.0121

G1X5.0336Y1.9470Z-0.0147

G1X5.0593Y1.9442Z-0.0173

G1X5.0845Y1.9402Z-0.0199

G1X5.1093Y1.9352Z-0.0224

G1X5.1336Y1.9289Z-0.0249

G1X5.1573Y1.9215Z-0.0274

G1X5.1805Y1.9129Z-0.0299

G1X5.2031Y1.9031Z-0.0323

G1X5.2251Y1.8922Z-0.0348

G1X5.2465Y1.8801Z-0.0372

G1X5.2672Y1.8669Z-0.0397

G1X5.2872Y1.8525Z-0.0422

G1X5.3066Y1.8371Z-0.0446

G1X5.3252Y1.8205Z-0.0471

G1X5.3432Y1.8029Z-0.0497

G1X5.3456Y1.8003Z-0.0500

G1X5.3432Y1.8029Z-0.0503

G1X5.3252Y1.8205Z-0.0529

G1X5.3066Y1.8371Z-0.0554

G1X5.2872Y1.8525Z-0.0578

G1X5.2672Y1.8669Z-0.0603

G1X5.2465Y1.8801Z-0.0628

G1X5.2251Y1.8922Z-0.0652

G1X5.2031Y1.9031Z-0.0677

G1X5.1805Y1.9129Z-0.0701

G1X5.1573Y1.9215Z-0.0726

G1X5.1336Y1.9289Z-0.0751

G1X5.1093Y1.9352Z-0.0776

G1X5.0845Y1.9402Z-0.0801

G1X5.0593Y1.9442Z-0.0827

G1X5.0336Y1.9470Z-0.0853

G1X5.0074Y1.9486Z-0.0879

G1X4.9808Y1.9492Z-0.0906

G1X4.9567Y1.9487Z-0.0930

G1X4.9331Y1.9474Z-0.0953

G1X4.9097Y1.9451Z-0.0977

G1X4.8867Y1.9418Z-0.1000

G1X4.9097Y1.9451F60.0

G1X4.9331Y1.9474

G1X4.9567Y1.9487

G1X4.9808Y1.9492

G1X5.0074Y1.9486

G1X5.0336Y1.9470

G1X5.0593Y1.9442

G1X5.0845Y1.9402

G1X5.1093Y1.9352

G1X5.1336Y1.9289

G1X5.1573Y1.9215

G1X5.1805Y1.9129

G1X5.2031Y1.9031

G1X5.2251Y1.8922

G1X5.2465Y1.8801

G1X5.2672Y1.8669

G1X5.2872Y1.8525

G1X5.3066Y1.8371

G1X5.3252Y1.8205

G1X5.3432Y1.8029

G1X5.3604Y1.7841

G1X5.3766Y1.7644

G1X5.3916Y1.7437

G1X5.4055Y1.7223

G1X5.4183Y1.7000

G1X5.4299Y1.6770

G1X5.4404Y1.6531

G1X5.4497Y1.6286

G1X5.4578Y1.6033

G1X5.4649Y1.5774

G1X5.4708Y1.5507

G1X5.4756Y1.5235

G1X5.4793Y1.4955

G1X5.4819Y1.4669

G1X5.4835Y1.4377

G1X5.4840Y1.4078

G1X5.4831Y1.3611

G1X5.4804Y1.3165

G1X5.4758Y1.2740

G1X5.4693Y1.2337

G1X5.4608Y1.1953

G1X5.4503Y1.1596

G1X5.4374Y1.1249

G1X5.4222Y1.0925

G1X5.4057Y1.0636

G1X5.3872Y1.0360

G1X5.3669Y1.0099

G1X5.3447Y0.9855

G1X5.3206Y0.9628

G1X5.2949Y0.9418

G1X5.2675Y0.9227

G1X5.2386Y0.9053

G1X5.2086Y0.8900

G1X5.1780Y0.8767

G1X5.1466Y0.8654

G1X5.1146Y0.8562

G1X5.0820Y0.8490

G1X5.0488Y0.8439

G1X5.0150Y0.8408

G1X4.9811Y0.8398

G1X4.9538Y0.8404

G1X4.9273Y0.8420

G1X4.9012Y0.8448

G1X4.8757Y0.8487

G1X4.8507Y0.8538

G1X4.8262Y0.8600

G1X4.8023Y0.8674

G1X4.7789Y0.8759

G1X4.7562Y0.8857

G1X4.7340Y0.8966

G1X4.7126Y0.9087

G1X4.6918Y0.9219

G1X4.6717Y0.9362

G1X4.6524Y0.9517

G1X4.6338Y0.9682

G1X4.6159Y0.9859

G1X4.5988Y1.0048

G1X4.5827Y1.0248

G1X4.5677Y1.0458

G1X4.5539Y1.0677

G1X4.5413Y1.0905

G1X4.5298Y1.1142

G1X4.5195Y1.1388

G1X4.5103Y1.1641

G1X4.5023Y1.1902

G1X4.4954Y1.2171

G1X4.4896Y1.2448

G1X4.4849Y1.2733

G1X4.4813Y1.3024

G1X4.4787Y1.3324

G1X4.4772Y1.3631

G1X4.4766Y1.3946

G1X4.4773Y1.4289

G1X4.4791Y1.4624

G1X4.4822Y1.4950

G1X4.4865Y1.5267

G1X4.4921Y1.5575

G1X4.4991Y1.5873

G1X4.5074Y1.6162

G1X4.5170Y1.6442

G1X4.5280Y1.6712

G1X4.5404Y1.6971

G1X4.5541Y1.7220

G1X4.5693Y1.7458

G1X4.5859Y1.7685

G1X4.6038Y1.7900

G1X4.6231Y1.8103

G1X4.6435Y1.8292

G1X4.6614Y1.8439

G1X4.6794Y1.8574

G1X4.6981Y1.8701

G1X4.7172Y1.8818

G1X4.7368Y1.8927

G1X4.7569Y1.9025

G1X4.7775Y1.9115

G1X4.7985Y1.9195

G1X4.8200Y1.9265

G1X4.8419Y1.9326

G1X4.8641Y1.9377

G1X4.8867Y1.9418

G0Z0.2000

G0X5.6086Y1.9279

G1Z0.0000F10.0

G1X5.7523Z-0.0144

G1X5.7609Y1.9273Z-0.0152

G1X5.7697Y1.9254Z-0.0161

G1X5.7784Y1.9221Z-0.0171

G1X5.7867Y1.9175Z-0.0180

G1X5.7942Y1.9117Z-0.0190

G1X5.8007Y1.9049Z-0.0199

G1X5.8060Y1.8973Z-0.0208

G1X5.8100Y1.8892Z-0.0217

G1X5.8128Y1.8809Z-0.0226

G1X5.8283Y1.8911Z-0.0245

G1X5.8503Y1.9034Z-0.0270

G1X5.8731Y1.9143Z-0.0295

G1X5.8967Y1.9237Z-0.0320

G1X5.9211Y1.9316Z-0.0346

G1X5.9460Y1.9380Z-0.0372

G1X5.9717Y1.9429Z-0.0398

G1X5.9979Y1.9464Z-0.0424

G1X6.0246Y1.9485Z-0.0451

G1X6.0519Y1.9492Z-0.0479

G1X6.0734Y1.9487Z-0.0500

G1X6.0519Y1.9492Z-0.0521

G1X6.0246Y1.9485Z-0.0549

G1X5.9979Y1.9464Z-0.0576

G1X5.9717Y1.9429Z-0.0602

G1X5.9460Y1.9380Z-0.0628

G1X5.9211Y1.9316Z-0.0654

G1X5.8967Y1.9237Z-0.0680

G1X5.8731Y1.9143Z-0.0705

G1X5.8503Y1.9034Z-0.0730

G1X5.8283Y1.8911Z-0.0755

G1X5.8128Y1.8809Z-0.0774

G1X5.8100Y1.8892Z-0.0783

G1X5.8060Y1.8973Z-0.0792

G1X5.8007Y1.9049Z-0.0801

G1X5.7942Y1.9117Z-0.0810

G1X5.7867Y1.9175Z-0.0820

G1X5.7784Y1.9221Z-0.0829

G1X5.7697Y1.9254Z-0.0839

G1X5.7609Y1.9273Z-0.0848

G1X5.7523Y1.9279Z-0.0856

G1X5.6086Z-0.1000

G1X5.7523F60.0

G2X5.8128Y1.8809I0.0000J-0.0625

G1X5.8283Y1.8911

G1X5.8503Y1.9034

G1X5.8731Y1.9143

G1X5.8967Y1.9237

G1X5.9211Y1.9316

G1X5.9460Y1.9380

G1X5.9717Y1.9429

G1X5.9979Y1.9464

G1X6.0246Y1.9485

G1X6.0519Y1.9492

G1X6.0759Y1.9486

G1X6.0995Y1.9470

G1X6.1228Y1.9443

G1X6.1457Y1.9404

G1X6.1682Y1.9354

G1X6.1903Y1.9292

G1X6.2119Y1.9220

G1X6.2331Y1.9136

G1X6.2535Y1.9042

G1X6.2728Y1.8940

G1X6.2912Y1.8828

G1X6.3085Y1.8707

G1X6.3247Y1.8576

G1X6.3398Y1.8434

G1X6.3537Y1.8283

G1X6.3660Y1.8125

G1X6.3768Y1.7965

G1X6.3864Y1.7802

G1X6.3952Y1.7633

G1X6.4031Y1.7458

G1X6.4102Y1.7278

G1X6.4163Y1.7092

G1X6.4217Y1.6902

G1X6.4265Y1.6695

G1X6.4310Y1.6386

G1X6.4341Y1.6006

G1X6.4358Y1.5555

G1X6.4364Y1.5030

G1Y0.9236

G2X6.3739Y0.8611I-0.0625J0.0000

G1X6.2143

G2X6.1518Y0.9236I0.0000J0.0625

G1X6.1515Y1.5185

G1X6.1494Y1.5572

G1X6.1454Y1.5884

G1X6.1401Y1.6115

G1X6.1342Y1.6269

G1X6.1268Y1.6394

G1X6.1172Y1.6506

G1X6.1046Y1.6611

G1X6.0891Y1.6705

G1X6.0717Y1.6778

G1X6.0523Y1.6828

G1X6.0303Y1.6855

G1X6.0186Y1.6858

G1X5.9984Y1.6850

G1X5.9796Y1.6826

G1X5.9618Y1.6788

G1X5.9449Y1.6734

G1X5.9287Y1.6666

G1X5.9132Y1.6582

G1X5.8981Y1.6482

G1X5.8834Y1.6365

G1X5.8733Y1.6260

G1X5.8637Y1.6121

G1X5.8546Y1.5941

G1X5.8466Y1.5717

G1X5.8399Y1.5449

G1X5.8349Y1.5136

G1X5.8318Y1.4779

G1X5.8307Y1.4376

G1Y0.9236

G2X5.7682Y0.8611I-0.0625J0.0000

G1X5.6086

G2X5.5461Y0.9236I0.0000J0.0625

G1Y1.8654

G2X5.6086Y1.9279I0.0625J0.0000

G0Z0.2000

G0X3.4051Y1.2438

G1Z0.0000F10.0

G1X3.3945Y1.2374Z-0.0012

G1X3.3860Y1.2304Z-0.0023

G1X3.3789Y1.2225Z-0.0034

G1X3.3729Y1.2133Z-0.0045

G1X3.3685Y1.2036Z-0.0056

G1X3.3655Y1.1935Z-0.0066

G1X3.3638Y1.1768Z-0.0083

G1X3.3643Y1.1669Z-0.0093

G1X3.3655Y1.1585Z-0.0101

G1X3.3676Y1.1508Z-0.0109

G1X3.3703Y1.1437Z-0.0117

G1X3.3739Y1.1370Z-0.0125

G1X3.3783Y1.1303Z-0.0133

G1X3.3840Y1.1236Z-0.0141

G1X3.3906Y1.1172Z-0.0151

G1X3.3980Y1.1115Z-0.0160

G1X3.4062Y1.1065Z-0.0169

G1X3.4158Y1.1019Z-0.0180

G1X3.4272Y1.0979Z-0.0192

G1X3.4403Y1.0946Z-0.0206

G1X3.4554Y1.0921Z-0.0221

G1X3.4723Y1.0905Z-0.0238

G1X3.4911Y1.0899Z-0.0257

G1X3.5102Y1.0904Z-0.0276

G1X3.5286Y1.0920Z-0.0294

G1X3.5463Y1.0946Z-0.0312

G1X3.5632Y1.0982Z-0.0330

G1X3.5794Y1.1028Z-0.0346

G1X3.5950Y1.1083Z-0.0363

G1X3.6100Y1.1148Z-0.0379

G1X3.6244Y1.1223Z-0.0396

G1X3.6380Y1.1305Z-0.0411

G1X3.6505Y1.1394Z-0.0427

G1X3.6618Y1.1488Z-0.0441

G1X3.6721Y1.1587Z-0.0456

G1X3.6814Y1.1693Z-0.0470

G1X3.6899Y1.1805Z-0.0484

G1X3.6974Y1.1925Z-0.0498

G1X3.6984Y1.1942Z-0.0500

G1X3.6974Y1.1925Z-0.0502

G1X3.6899Y1.1805Z-0.0516

G1X3.6814Y1.1693Z-0.0530

G1X3.6721Y1.1587Z-0.0544

G1X3.6618Y1.1488Z-0.0559

G1X3.6505Y1.1394Z-0.0573

G1X3.6380Y1.1305Z-0.0589

G1X3.6244Y1.1223Z-0.0604

G1X3.6100Y1.1148Z-0.0621

G1X3.5950Y1.1083Z-0.0637

G1X3.5794Y1.1028Z-0.0654

G1X3.5632Y1.0982Z-0.0670

G1X3.5463Y1.0946Z-0.0688

G1X3.5286Y1.0920Z-0.0706

G1X3.5102Y1.0904Z-0.0724

G1X3.4911Y1.0899Z-0.0743

G1X3.4723Y1.0905Z-0.0762

G1X3.4554Y1.0921Z-0.0779

G1X3.4403Y1.0946Z-0.0794

G1X3.4272Y1.0979Z-0.0808

G1X3.4158Y1.1019Z-0.0820

G1X3.4062Y1.1065Z-0.0831

G1X3.3980Y1.1115Z-0.0840

G1X3.3906Y1.1172Z-0.0849

G1X3.3840Y1.1236Z-0.0859

G1X3.3783Y1.1303Z-0.0867

G1X3.3739Y1.1370Z-0.0875

G1X3.3703Y1.1437Z-0.0883

G1X3.3676Y1.1508Z-0.0891

G1X3.3655Y1.1585Z-0.0899

G1X3.3643Y1.1669Z-0.0907

G1X3.3638Y1.1768Z-0.0917

G1X3.3655Y1.1935Z-0.0934

G1X3.3685Y1.2036Z-0.0944

G1X3.3729Y1.2133Z-0.0955

G1X3.3789Y1.2225Z-0.0966

G1X3.3860Y1.2304Z-0.0977

G1X3.3945Y1.2374Z-0.0988

G1X3.4051Y1.2438Z-0.1000

G1X3.3945Y1.2374F60.0

G1X3.3860Y1.2304

G1X3.3789Y1.2225

G1X3.3729Y1.2133

G1X3.3685Y1.2036

G1X3.3655Y1.1935

G1X3.3638Y1.1768

G1X3.3643Y1.1669

G1X3.3655Y1.1585

G1X3.3676Y1.1508

G1X3.3703Y1.1437

G1X3.3739Y1.1370

G1X3.3783Y1.1303

G1X3.3840Y1.1236

G1X3.3906Y1.1172

G1X3.3980Y1.1115

G1X3.4062Y1.1065

G1X3.4158Y1.1019

G1X3.4272Y1.0979

G1X3.4403Y1.0946

G1X3.4554Y1.0921

G1X3.4723Y1.0905

G1X3.4911Y1.0899

G1X3.5102Y1.0904

G1X3.5286Y1.0920

G1X3.5463Y1.0946

G1X3.5632Y1.0982

G1X3.5794Y1.1028

G1X3.5950Y1.1083

G1X3.6100Y1.1148

G1X3.6244Y1.1223

G1X3.6380Y1.1305

G1X3.6505Y1.1394

G1X3.6618Y1.1488

G1X3.6721Y1.1587

G1X3.6814Y1.1693

G1X3.6899Y1.1805

G1X3.6974Y1.1925

G1X3.7040Y1.2049

G1X3.7080Y1.2144

G1X3.7118Y1.2258

G1X3.7152Y1.2394

G1X3.7181Y1.2551

G1X3.7205Y1.2728

G1X3.7232Y1.3103

G1X3.6918Y1.3026

G1X3.6562Y1.2949

G1X3.6182Y1.2876

G1X3.4911Y1.2672

G1X3.4557Y1.2600

G1X3.4281Y1.2528

G1X3.4112Y1.2467

G1X3.4051Y1.2438

G0Z0.2000

G0X4.7668Y1.4347

G1Z0.0000F10.0

G1X4.7657Y1.3945Z-0.0040

G1X4.7668Y1.3544Z-0.0080

G1X4.7702Y1.3175Z-0.0117

G1X4.7756Y1.2840Z-0.0151

G1X4.7830Y1.2538Z-0.0182

G1X4.7921Y1.2270Z-0.0211

G1X4.8029Y1.2034Z-0.0237

G1X4.8153Y1.1827Z-0.0261

G1X4.8293Y1.1647Z-0.0284

G1X4.8452Y1.1481Z-0.0307

G1X4.8619Y1.1341Z-0.0328

G1X4.8791Y1.1224Z-0.0349

G1X4.8971Y1.1131Z-0.0369

G1X4.9160Y1.1057Z-0.0390

G1X4.9360Y1.1005Z-0.0411

G1X4.9576Y1.0972Z-0.0432

G1X4.9808Y1.0961Z-0.0456

G1X5.0037Y1.0972Z-0.0478

G1X5.0250Y1.1005Z-0.0500

G1X5.0037Y1.0972Z-0.0522

G1X4.9808Y1.0961Z-0.0544

G1X4.9576Y1.0972Z-0.0568

G1X4.9360Y1.1005Z-0.0589

G1X4.9160Y1.1057Z-0.0610

G1X4.8971Y1.1131Z-0.0631

G1X4.8791Y1.1224Z-0.0651

G1X4.8619Y1.1341Z-0.0672

G1X4.8452Y1.1481Z-0.0693

G1X4.8293Y1.1647Z-0.0716

G1X4.8153Y1.1827Z-0.0739

G1X4.8029Y1.2034Z-0.0763

G1X4.7921Y1.2270Z-0.0789

G1X4.7830Y1.2538Z-0.0818

G1X4.7756Y1.2840Z-0.0849

G1X4.7702Y1.3175Z-0.0883

G1X4.7668Y1.3544Z-0.0920

G1X4.7657Y1.3945Z-0.0960

G1X4.7668Y1.4347Z-0.1000

G1X4.7657Y1.3945F60.0

G1X4.7668Y1.3544

G1X4.7702Y1.3175

G1X4.7756Y1.2840

G1X4.7830Y1.2538

G1X4.7921Y1.2270

G1X4.8029Y1.2034

G1X4.8153Y1.1827

G1X4.8293Y1.1647

G1X4.8452Y1.1481

G1X4.8619Y1.1341

G1X4.8791Y1.1224

G1X4.8971Y1.1131

G1X4.9160Y1.1057

G1X4.9360Y1.1005

G1X4.9576Y1.0972

G1X4.9808Y1.0961

G1X5.0037Y1.0972

G1X5.0250Y1.1005

G1X5.0449Y1.1058

G1X5.0636Y1.1131

G1X5.0815Y1.1225

G1X5.0986Y1.1342

G1X5.1153Y1.1483

G1X5.1312Y1.1650

G1X5.1452Y1.1831

G1X5.1575Y1.2040

G1X5.1684Y1.2280

G1X5.1776Y1.2554

G1X5.1850Y1.2863

G1X5.1905Y1.3207

G1X5.1938Y1.3585

G1X5.1949Y1.3998

G1X5.1938Y1.4384

G1X5.1905Y1.4739

G1X5.1851Y1.5062

G1X5.1777Y1.5354

G1X5.1685Y1.5615

G1X5.1577Y1.5847

G1X5.1452Y1.6052

G1X5.1310Y1.6233

G1X5.1149Y1.6400

G1X5.0982Y1.6541

G1X5.0810Y1.6658

G1X5.0631Y1.6752

G1X5.0444Y1.6824

G1X5.0246Y1.6877

G1X5.0034Y1.6909

G1X4.9807Y1.6920

G1X4.9576Y1.6909

G1X4.9360Y1.6877

G1X4.9159Y1.6824

G1X4.8969Y1.6752

G1X4.8790Y1.6658

G1X4.8618Y1.6542

G1X4.8451Y1.6402

G1X4.8292Y1.6238

G1X4.8152Y1.6059

G1X4.8029Y1.5853

G1X4.7921Y1.5618

G1X4.7829Y1.5350

G1X4.7756Y1.5050

G1X4.7702Y1.4715

G1X4.7668Y1.4347

G0Z0.2000

G0X1.5706Y1.8688

G1Z0.0000F10.0

G1X1.5527Y1.8173Z-0.0054

G1X1.4414Y1.5200Z-0.0372

G1X1.5694Z-0.0500

G1X1.4414Z-0.0628

G1X1.5527Y1.8173Z-0.0946

G1X1.5706Y1.8688Z-0.1000

G1X1.5527Y1.8173F60.0

G1X1.4414Y1.5200

G1X1.7016

G1X1.5706Y1.8688

G0Z0.2000

M5

G0Z0.8000

G0X0.0000Y0.0000

M2

14

That post includes M6 Toolchanges, so it should work with the BitSetter.

2 Likes
15

it worked! Thank you
