Curious on how to approach something like this on CNC?

How To
1

New to CNC in general. Would like to design holders for game tiles like in this picture.

My question would be mostly around milling curved objects like this.

image1588Ă—1588 103 KB

2

You will want a full-fledged 3D CAD/CAM program such as:

1 Like
3

Thanks Will! I’ll look at Alibre and similar, I am somewhat familiar with using fusion as well though on the CAM side not as much.

I think in terms of designing it, I get the general idea but translating that to the actually milling I’m not sure I guess how to achieve the shape best. Is it possible vertically? Would you carve the concave side first then flip it?

4

How a part once designed is machined is a topic which runs up against:

  • stock size and machine working area — certain orientations may not be possible due to Z-axis limitations
  • workholding — how will the stock be clamped/secured?
  • will a fixture be needed for one or more additional operations?
  • tabs/sprues — will it be necessary to add tabs/sprues if a fixture alone is not sufficient?

For an example of one approach to this sort of thing see:

Note that there are entire books written on jigs and fixtures:

The search term you want is “Design for Manufacturing”.

4 Likes
5

Very helpful resources, thanks Will.

6

I would design the object in a 3d software like sketchup or tinkercad (because i know them). Export it in .stl and then import the file in CC to carve it using 3D toolpath

3 Likes
